Description
Key Features & Benefits:
-
DIN975 & DIN976 Compliance – Manufactured to the rigorous DIN975 (threaded rod) and DIN976 (stud bolt) dimensional and performance specifications, ensuring consistent thread geometry, straightness, and fitment for interchangeability with standard hardware and nuts.
-
Full Thread Design – The thread runs continuously from end to end, providing maximum thread engagement and allowing for precise adjustment in applications where clamping length is critical. This design also enables double‑nut locking, spacer adjustments, and through‑hole mounting where full thread coverage is required.
-
Aerospace‑Grade GR5 Titanium – Made from Ti‑6Al‑4V alloy, offering a tensile strength exceeding 900 MPa with a density approximately 60% that of steel. This provides exceptional strength‑to‑weight performance, reducing overall assembly mass while maintaining load‑carrying capacity – a critical advantage for weight‑sensitive applications.
-
Broad Size Range (M6–M36) – Available in diameters from M6 to M36, accommodating a wide variety of fastening needs – from small‑diameter studs for light machinery to heavy‑duty M36 studs for structural and industrial applications. Custom lengths are available upon request to suit your specific requirements.
-
Corrosion‑Resistant for Harsh Environments – Titanium’s natural passive oxide layer provides outstanding resistance to rust, saltwater, chemicals, acids, and extreme weather conditions. This ensures long‑term reliability and reduced maintenance costs in marine, chemical processing, and outdoor applications where carbon steel studs would quickly corrode.
-
100% Quality Inspection – Every stud undergoes rigorous dimensional and mechanical inspection to ensure consistent quality and performance. This includes thread gauging, concentricity checks, surface finish verification, and tensile testing – guaranteeing that each stud meets the required specifications.
-
BOZE Brand Quality – Backed by the trusted BOZE brand, these studs are manufactured to the highest standards of precision and durability, with a reputation for reliable performance in demanding industrial and automotive applications.
-
Reliable Supply & Flexible MOQ – With a minimum order quantity of 100 pieces, sample availability upon request, and packaging in cartons, we provide a dependable supply chain for both small workshops and large‑scale industrial clients.
Technical Specification Table
| Item | Specification |
|---|---|
| Product Name | Titanium Alloy Threaded Studs – Full Thread |
| Material | Titanium Alloy GR5 (Ti‑6Al‑4V) |
| Grade | GR5 (Ti‑6Al‑4V) |
| Standard | DIN975 / DIN976 (custom standards available upon request) |
| Diameter Range | M6 – M36 (custom lengths available) |
| Thread Form | Full thread (continuous from end to end) – metric standard |
| Tensile Strength | ≥ 900 MPa (typical) |
| Density | ≈ 4.43 g/cm³ (approx. 60% of steel) |
| Quality Control | 100% Inspection (dimensional and mechanical) |
| Brand | BOZE |
| Corrosion Resistance | Excellent – titanium’s natural oxide layer |
| Application | Automotive, motorsports, marine, chemical processing, general engineering |
| MOQ | 100 pcs |
| Sample Availability | Yes (upon request) |
| Packaging | Carton Packing |
| Certification | ISO9001:2015 |
