Description
Key Features & Benefits:
-
Aerospace‑Grade GR5 Titanium – Made from Ti‑6Al‑4V alloy, offering a tensile strength exceeding 900 MPa with a density approximately 60% that of steel. This provides exceptional strength‑to‑weight performance – critical for weight‑sensitive electronic devices and portable equipment where every gram matters.
-
Countersunk (Flat Head) Design – The 90° countersunk head provides a flush, low‑profile finish when installed in countersunk holes, eliminating protrusions that could interfere with device assembly, housing fitment, or user handling. This is essential for electronics where smooth external surfaces and compact designs are required.
-
Torx Drive for Superior Torque Transfer – The Torx (star) recess provides a large contact area between the driver and fastener, significantly reducing cam‑out and stripping – even under high torque. This ensures consistent, reliable tightening and easier removal in electronics manufacturing, where automated assembly and high‑speed production are common.
-
CNC Machined for Ultra‑Precision – Manufactured using advanced CNC turning and milling processes to ensure tight tolerances on thread geometry, head dimensions, and concentricity. The excellent surface finish minimises galling risk and ensures consistent thread fitment – essential for delicate electronic assemblies.
-
Broad Size Range (M3–M8) & Lengths (30–500mm) – From M3 screws for securing circuit boards and display panels to M8 screws for heavy‑duty equipment chassis and structural mounts, this range covers a wide spectrum of electronics fastening needs. Custom lengths from 30mm to 500mm provide flexibility for various assembly stacks and spacing requirements.
-
Custom Colours Available – Available in a range of vibrant anodised colours: Rainbow, Gold, Blue, Black, Pink, and Purple – allowing you to colour‑code fasteners for assembly identification, match device aesthetics, or create a distinctive branded appearance. The anodised layer also enhances surface hardness and corrosion resistance.
-
Corrosion‑Resistant for Long‑Term Reliability – Titanium’s natural passive oxide layer provides outstanding resistance to moisture, humidity, and chemical exposure – ensuring long‑term reliability in electronics used in demanding environments, including industrial, outdoor, and portable applications.
-
Non‑Magnetic for Sensitive Electronics – Titanium is inherently non‑magnetic, making these screws ideal for applications near sensitive electronic components, magnetic sensors, and communication devices where magnetic interference must be minimised.
-
Quality Assurance & Sample Availability – Manufactured under an ISO9001:2015 certified quality system, with rigorous dimensional and mechanical inspections. Samples are available upon request for testing and approval. With a minimum order quantity of 100 pieces and standard delivery of 10‑15 working days, we cater to both development projects and volume production.
Technical Specification Table
| Item | Specification |
|---|---|
| Product Name | CNC Machined Custom GR5 Titanium Flat Head Torx Screws |
| Material | GR5 Titanium Alloy (Ti‑6Al‑4V) |
| Grade | GR5 (Ti‑6Al‑4V) |
| Size Range | M3 – M8 (custom lengths available) |
| Length Range | 30 – 500 mm (customisable) |
| Head Type | Countersunk / Flat Head (90° standard) |
| Drive | Torx (star recess) |
| Surface Finish | Anodised (custom colours) |
| Colour Options | Rainbow, Gold, Blue, Black, Pink, Purple (custom colours available) |
| Tensile Strength | ≥ 900 MPa (typical) |
| Density | ≈ 4.43 g/cm³ (approx. 60% of steel) |
| Key Features | Lightweight, non‑magnetic, corrosion‑resistant, high strength |
| Application | Electronics, consumer devices, computer hardware, industrial controls, telecommunications |
| MOQ | 100 pcs |
| Sample Availability | Available (upon request) |
| Delivery Time | 10‑15 Working Days (depends on order complexity) |
| Packaging | Plastic Bag + Carton Box |
| Certification | ISO9001:2015 |
